DS-60 Large-Capacity Hybrid VTOL Drone

stars, based on 0reviews
$27999.00 set
20items available
Add to Basket Inquire Now


DS-60 Large-Capacity Hybrid VTOL Drone



FQ-60 is especially designed for heavy-load missions, max take-off weight 60kg. With super long-time endurance, it can perform tasks of  emergency medicine delivery, geographic mapping, forest rescue, and border line patrol by carrying different payload, such as electro-optical/infrared cameras, orthophoto cameras and Lidar. Besides, the biggest highlight of FQ-60 is the electronic fuel injection(EFI) Engine and customized close-source flight control, which can provide a more reliable and stable flight.

DS-60 (Hybrid) Specification:

MTOW

60kg

Wingspan

4500mm

Length

2426mm

Max payload

15kg

Endurance

6~10h(according to the payload)

Cruising speed

27~30m/s

Stall speed

23m/s

Max flying speed

40m/s

Distance

500km

Working temperature

-20~45

Engine

DLE 120 EFI / GP123

Minimum circle radius

200m

Max take-off altitude

5000m

Max wind resistance

Take-off: level 6

Horizontal: level 7

Material

Glass fiber+carbon fiber+composite materials



DS-60 Large-Capacity Hybrid VTOL Drone
